Wholesale Magnetic Contactor For Air Conditioner With 240V/AC
Home / Product / Air-Conditioner Parts / Contactor & Transformer / Contactor / Magnetic Contactor For Air Conditioner With 240V/AC
Magnetic Contactor For Air Conditioner With 240V/AC

Magnetic Contactor For Air Conditioner With 240V/AC

Simple drop-in replacements for driers installed in refrigeration, air conditioning, and heat pump unit refrigerant lines.
Details: Designed to protect HVAC/R systems from acid and humidity. Max temperature 160F (70C) min temperature -40F (-40C)
Core: 99.99% Solid molecular sieve core to ensure complete humidity removal.
– High filtration capacity.
– Corrosion-resistant finish.
– 500 Psig safe working pressure.
– Hard copper on sweat connector types.
– High capacity for organic acids, inorganic acids, and oil breakdown products.
– ODF or SAE-type adaptors available.
– Suitable for R12, R22, R410A, R134A and R502 refrigerant.
– Models range from 1/4 to 1-1/8 Connections.
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
  • Magnetic Contactor For Air Conditioner With 240V/AC
PREV：No previous article
NEXT：No next article
Parameter
PART NO NO.OF POLES FULL LOAD AMPS RESISTIVE  AMPS LOCKED ROTOR
AMPS@240		 COIL VOLTAGE
DMA130 1 30 40 180 24
DMB130 1 30 40 150 120
DMC130 1 30 40 120 208/240
DMA225 2 25 35 150 24
DMB225 2 25 35 125 120
DMC225 2 25 35 100 208/240
DMA230 2 30 40 180 24
DMB230 2 30 40 150 120
DMC230 2 30 40 120 208/240
DMA240 2 40 50 240 24
DMB240 2 40 50 200 120
DMC240 2 40 50 160 208/240
DMA325 3 25 35 150 24
DMB325 3 25 35 125 120
DMC325 3 25 35 100 208/240
DMA330 3 30 40 180 24
DMB330 3 30 40 150 120
DMC330 3 30 40 120 208/240
DMA340 3 40 50 240 24
DMB340 3 40 50 200 120
DMC340 3 40 50 160 208/240
DMA350 3 50 60 300 24
DMB350 3 50 60 250 120
DMC350 3 50 60 200 208/240
DMA360 3 60 75 360 24
DMB360 3 60 75 300 120
DMC360 3 60 75 240 208/240
DMA375 3 75 93 450 24
DMB375 3 75 93 375 120
DMC375 3 75 93 300 208/240
DMA390 3 90 120 540 24
DMB390 3 90 120 450 120
DMC390 3 90 120 360 208/240
